HOW YOU SOLVE THIS Expanded Polystyrene wastes ?
Did you face the following trouble, Once waste EPS product are storage as hill day by day, also market is not acceptable EPS block or package with high percentage recycle material. What can I do ?
Here, I recommend you the solution as follows:
Let us change waste EPS-- To --GPPS
What is GPPS for ?
This material have a large application in many field with injection machine ,
Such as shell of TV ,refrig , Ac, bale, chair, palleter, electronic parts, toys and so on.
EPS PALLET HOME APPLIANCE SHELL
DAYLY LIFE PARTS
The following is recommend--------FOAM Pelletizer MACHINE
Output:50-70 kg/h
Density : Suitable for all density EPS products
Power consumption: 29Kw
Complete set include the following parts :
1, EPS Crusher
2, EPS Hopper with rotary system
3, Main machine with double-screw extruder, hydraulic system for filter net change
4, Water cooling slot tank
5, Dry system for pellets
6, Pellets cutter .
7, Stainless Pellets Tank
1, PROCESS OF Pelletizer MACHINE
Crusher: Strong crush capacity material hopper with rotary shaft
Big inlet product size 600x300mm Rotary system feed material
continuously and evenly
Double Screw to solve the normal problem for low density EPS items. The low density have less melting volume , If we take one screw only as traditional Pelletizer machine, so that So that the extruder PS line would be always broken , because of less feed capacity.
After extruder , the liquid PS line for go to cooling water for harden. Keep water temperature:35- 50 degree
Dry system will take water away of PS line. So that
Final Stage is Pelletizer Cutter
2, MAIN SPECIFICATION
1, Easy adjustment
All motor speed controlled by frequency converter , so it is easy for client to adjust feeder speed ;
Automatic temperature control, so easy to set temperature .
2, Double screw can recycle different density EPS products
one stage Screw and barrel: made of 45# STEEL , inlet mouth is coverd special alloy (screw dia.￠160,long dia.ratio 160*200*640 )
second stages screw
Screw and barrel: made of 38CrMoAl , inlet mouth is coverd special alloy (screw dia.￠90,long dia.ratio 90*130*850 )
3, Non stop filter net clean system, so the production can run continuously Two filter nets can be changed by hydraulic control
4, High quality material and brand components , keep stable quality
All efforts keep this machine stable quality , smooth running , easy operation
