6 meter VACUUM BLOCK MOLDING MACHINE (Horizontal) in Stock

6 meter VACUUM BLOCK MOLDING MACHINE (Horizontal) in Stock.

------ Great Price, Great Deal.

Photos:
















Specification:



Type: SPB-DF 6000
Mould size: 6100x1240x630mm
Block size: 6000x1200x600mm
Density range: 7~30kg/L
Capacity: approx.
10 min per cycle at density 15kg/m3, approx. 6 blocks/hour,
it means around 207.36 m3/ 8hours
Steam consumption: 40~60kg/cycle
Steam supply pressure: 6~8 bar
Compressed air consumption: 1.6~2.0m3 per cycle
Compressed air: 6 bar operating pressure
Power consumption: 13 kw
Electricity: 50HZ, 380V
Overall weight: 9,500kg
Overall size: 8,100 x 2,500 x 3,100mm
With main machine, exit line, vacuum system, filling system,
hydraulic system, made of profile steel,
galvanized iron and nylon net.
*Machine features.
1. Colored Touch Screen Panel,
2. PLC System .
3. Electrical contact pressure Gauges;
4. Butter Fly Valves
5. Material hopper
New improved mechanical design:
Big steam flow pipe low pressure energy saving
      New improve reasonable cross steaming design


Installation and Start-up:

A buyer will cover air round ticket, accommodation cost& meals, local transportation, interpreter
English-Chinese) and other necessary things during commissioning & tests running period.
-. Estimate commissioning & test-running periods will take about 5~8 working days by 1~2 persons.
-. USD100/day will be charged as commission fee for the technician each person.

Warranty:     12 months limited warranty starting from date of delivery excluding wear parts. Shipping cost for parts to be replaced during warranty period have to be borne by the customer.


Price: email us for the prices, james@epsole.com
